Neodymium Bar Magnets 3/2

3/2"x 1/2"x 1/16" is one of the popular sizes in neodymium block bar category, and also supplied as standard magnets in the USA. Custom grades from N35 to N52 are available for the magnets. Nickel plating make the strong rectangle bar magnets 3/2"x 1/2"x 1/16" have shiny appearance, which looks like stainless steel. They can be provided with 3M-adhesive backing when magnetized through the thickness. Rectangular rare earth neodymium bar magnets of N52 have a pull force of 3.6kg. Retail packaging can be supplied to distributors.

Characteristics Of Neodymium Bar Magnets 3/2

Remanence (Br): 14300-14800 Gauss for 3/2"x1/2"x1/16" block bar magnets N52.

Coercivity (Hcj): ≥876.

Magnetic Energy Product (BH-max): 50-53 MGOe for N52 rectangle bar magnets 3/2"x1/2"x1/16".

Max. Working Temperature: 60℃.

Corrosion Resistance: plating needed for 3/2"x1/2"x1/16" neodymium bar magnets

Specification Of Neodymium Block Bar Magnets 3/2" x 1/2" x 1/16"-N52


Category

Bar Magnet

Material

Sintered-NdFeB

Grade

N52

Length (L)

3/2" (38.1mm)

Width (W)

1/2" (12.7mm)

Thickness (T)

1/16" (1.5mm)

Magnetization direction

Through Thickness

Coating

NiCuNi

Strength

approx. 8.1LBs

Weight(1 piece)

5.7g

Tolerance

+/-0.05mm

Max.Working Temp.

80℃

Central Surface Field

1227 Gauss


Safety Warning:

  • Neodymium bar magnets are easy to break, but if used properly, they can also be used permanently.

  • Keep the strong neodymium bar magnets away from pacemakers.

  • Powerful neodymium bar magnets are not suitable for children and may cause injury.

  • If the bar magnet is damaged, dispose of it thoroughly.
